TCDS8646-3L
7 in (18 cm) 6-Digit LED Top Display Panel with 4 in (10.2 cm) 6-Digit Bottom Display Panel (red, green, blue, or amber)
- 7 in (18 cm) 6-digit LED top display with 4 in (10.2 cm) 6-digit bottom display
- Display colors available in red, green, blue or amber
- Adjustable brightness levels with auto-dimming option
- Display time in 12- or 24-hour format - hh:mm:ss
- Display date in dd:mm:yy, mm:dd:yy, or yy:mm:dd
- Display available without 3-digit alpha character
- Automatically detects IRIG-B, SMPTE 12M, 309M, 24/25/30 fps, 29.97 drop frame
- Fully configurable Daylight Saving Time parameters
TCDS8646-3AL Digital Clock
The TCDS8646-3AL digital clock syncs to IRIG-B, SMPTE and EBU time codes for accurate traceable time. Each unit configures to time zone and daylight savings time parameters. WinDiscovery software is included.
Reference Documents
SpecificationsTCDS8646 Digital Clock
Connectors
- BNC female
- 3-pin terminal block
- USB for configuration
- IEC Stnd A/C Power
Power
- International IEC AC 90-240v, 50/60 Hz
- Power consumption <15W
Operating Parameters
- Temperature: 0 to 60°C
- Humidity: Up to 90% (non-condensing)
Physical
- Stainless steel chassis
- Size: 39.4w x 15h x 2.63d in (100w x 38h x 6.7d cm),
Weight: 24 lbs (11 kg)
Compliance
- FCC, ROHS, CE Marked, ANSI
